Air Operated Pumps - Trigger Operated

X

Pefect for transferring oils, anti-freeze, mild acids etc.

Self-priming, air-operated piston pump, compatible with oils and most other fluids found in conventional steel drums/plastic containers.
Polypropylene with acetal piston.
Air regulator valve controls a flow rate of 270ml per stroke. Trickle feed tap allows for positive dispensing.
Max./min. air pressure: 7/2 bar.
Maintenance-free air changeover valve and aluminium air cylinder.
Telescopic uptake tube with a non-return valve. Length: 400-915mm.
Noise level: 74dB.
Pump alignment locking ring. 2 BSP drum connection.
Choose between Nitrile, Viton or EPDM seals:
Nitrile Seals are suitable for lubricating oils, diesel, cutting oils, etc.
Viton Seals are suitable for transmission fluids, antifreeze, AdBlue many chemicals and in-organic acids stored in plastic containers.
E.P.D.M Seals are suitable for a more specialised range of fluids such as alcohols, diluted alkalis and organic acids.

See more information...

Made in UK

From

£117.90

excl. VAT

£141.48 incl. VAT

unit

Item code: : Select a use

Add to Basket

Free delivery on all orders
Free returns within 30 days
Pay by card, account or Paypal
We'll beat any price by 5%

Description

Pefect for transferring oils, anti-freeze, mild acids etc.

Self-priming, air-operated piston pump, compatible with oils and most other fluids found in conventional steel drums/plastic containers.
Polypropylene with acetal piston.
Air regulator valve controls a flow rate of 270ml per stroke. Trickle feed tap allows for positive dispensing.
Max./min. air pressure: 7/2 bar.
Maintenance-free air changeover valve and aluminium air cylinder.
Telescopic uptake tube with a non-return valve. Length: 400-915mm.
Noise level: 74dB.
Pump alignment locking ring. 2 BSP drum connection.
Choose between Nitrile, Viton or EPDM seals:
Nitrile Seals are suitable for lubricating oils, diesel, cutting oils, etc.
Viton Seals are suitable for transmission fluids, antifreeze, AdBlue many chemicals and in-organic acids stored in plastic containers.
E.P.D.M Seals are suitable for a more specialised range of fluids such as alcohols, diluted alkalis and organic acids.

Please Note: this pump unit is not suitable for dispensing/transferring petroleum spirit. Flow gauges are available separately.

Made in UK

Environmental and/or social benefits

This packaging is 100% recyclable, which means that at the end of its life, all of its components can be recycled separately via specific recycling facilities.
This packaging is either partially or entirely recycled, which means that it has been made using materials from recycling facilities (refer to the technical specifications for more information).

Specifications

Product Information

Product Name	Air Operated Pumps - Trigger Operated
Packaging	unit

Technical Specification

Immersion tube length (mm)	340 mm
Height (mm)	540 mm
Weight (kg)	2.5 kg
Percentage recycled (%)	100 %
Fully recyclable packaging	Yes - 100%
Product origin	Made in UK
Recycled packaging (%)	100 %
Contains recyclable materials	Yes - 100%
